Leading Innovations In Sustainable Urban Drainage
Unique Patented System of Resin Bound Gravel Over Recycled Car Tyres
- SUDS Compliant, Totally Permeable, BREEAM Accredited
- 2 Part Cold Poured System
- High Density Range Available For Increased Weight Loading
- Minimal Dig Out • Unique Patented System Utilising A Recycled Tyre Sub base
- Fast Installation, Extremely Durable , Low Maintenance
- Full 360 Degree Attenuation, Effective Hydrobrake
- BRE Tested For Impact and Freeze Thaw
- Available In a Variety Of Colours Options
Sudstech permeable paving is an eco friendly SUDS-compliant (Sustainable Urban Drainage Systems) water management solution developed for both the commercial and public sector. Unlike other resin bound products the Sudstech system utilises a recycled car tyre sub base eliminating delamination and clogging, ensuring unrivalled porosity of 50,000 ltrs per m2 per hour.
The Sudstech system has been developed over the past 5 years and has been rigorously tested at the British Research Establishment for both impact and freeze thaw. The use of a Sudstech surfacing in conjunction with a permeable sub-base based SUDS system could achieve up to 4 BREEAM credits under the latest revisions.
All of our finishes are made from natural stone sourced in the UK. We use varying grades of angular aggregate to maximise the strength and durability of our surfaces. Selected finishes can be modified to fit additional specifications such as colour variation and weight loading capacity.
“We Now Offer A 10 Year Porosity Guarantee”
DLR Crossrail (Canary Wharf)
Sudstech have recently installed their system in the new DLR Crossrail station at Canary Wharf in central London. The surface is featured throughout the station’s iconic roof top park. Due to the garden’s semi open air design and the hi… Read More
Magic Roundabout (Plough Roundabout)
For pedestrians, crossing the road is a particularly difficult challenge, especially since the subway has been frequently submerged in up to six feet of water. This underpass has now recently been re-opened following resurfacing works using the… Read More
Lee Valley Cycle Superhighway
Waltham Forest introduced the scheme to local businesses and residents back in February 2015. Their mission was to establish fully protected cycle lanes called ‘Segregated Cycle Tracks’ running both ways from the borough… Read More
Sudstech Is Available In 13 Exciting Finishes
Is Planning Permission Required?
No. Sudstech is fully Suds compliant and is classed as a soak away.
What's the difference between Sudstech and Standard Resin Bound laid on tarmac/concrete?
Sudstech’s patented design utilises a recycled tyre sub base that is slightly flexible. This allows water to naturally return to the water table. With a resin system that is laid on to concrete or Tarmac water flows through the resin but cannot pass back in to the ground. Should water freeze between the permeable top course and the impermeable base delamination and subsequent breaking up of the surface can occur.
I already have concrete or tarmac that I don’t want to remove can I lay Sudstech on top of that?
Yes, in most cases this can be achieved by adapting the existing surface We would be happy to advise you.
Does the Sudstech surface feel springy or bouncy to walk on?
No, the rubber sub base is combined with stone and special resins and while the surface is flexible enough to withstand freeze thaw conditions and prevent clogging it will feel no different to any other surface in use.
How much maintenance will Sudstech require in comparison to other resin systems?
Very little. As we have already mentioned the surface will agitate grit and dust through the surface. Should soil be spilt on an area that has very little foot traffic it can be vacuumed or power washed on a low setting. Other resin manufacturers require the area to be treated with salt in frosty conditions and cleaned off as soon as the weather improves.
Does Sudstech carry a guarantee?
Yes. Sudstech carries a 10 year porosity guarantee and in addition to this we also provide a ten year porosity guarantee. Unlike other companies we guarantee both our wearing top course and our rubber sub base.
Has Sudstech been tested?
Yes. Sudstech has been tested by BRE The British research establishment for impact resistance and freeze thaw safety.
What ground works are required?
Sudstech is installed on to a preprepared base of 200mm of type 3 aggregate with ridged edging of your choice cemented in to place. We are happy to advise your contractor.
SUDS (Sustainable Urban Drainage solution) is new legislation brought into action alongside the Water Management Act 2010. SUDS is a legal requirement in planning to prevent surface water run off and the severe environmental impacts it causes.
In addition to SUDS compliance Sudstech’s rubber sub base safely utilises 3 car tyres on average for every square metre laid, reducing environmental impact by exploiting otherwise unusable and potentially harmful materials.
Rapid water run off from hard paving has severe environmental impacts. These include downstream flooding, the transfer of pollutants into watercourses and depletion of ground water levels.
Sudstech’s unique solution overcomes these problems by allowing drainage infiltration on site. This is the preferred water dispersal option of the Environment Agency and the focus of the SUDS legislation.
